Cucumber Lighting Controls PIRDMCRW PIR Sensor DALI Dimming Ceiling Recessed White RAL9010

Cucumber Lighting Controls PIRDMCRW PIR Sensor DALI Dimming Ceiling Recessed White RAL9010

SKU PIRDMCRW
£0
£108.00 - £108.00
£108.00 inc VAT £90.00 exc VAT
£108.00 - £108.00
£108.00 inc VAT £90.00 exc VAT inc VAT £90.00 exc VAT
 More payment options

Estimated delivery time: 3-4 working days

Description

Main Features:

  • 2 part modular construction
  • Colour coded housings = yellow for switching;
    green for dimming
  • Suitable for either surface or flush mounting
  • Large wiring compartment with push-fit terminals
    including Earth connections
  • Quick setup menu reducing time on-site for
    programming
  • Over the air software updates
Specification
  • Supply Voltage 100VAC to 230VAC
  • Supply Frequency 50/60Hz
  • Relay Max. Output Current 6 Amps @ 230VAC
    No of DALI Drivers 10 max. using sensor relay
    (Please refer to Fig.1 wiring diagram)
    20 max. not using sensor relay
    (Please refer to Fig.2 wiring diagram)
    Circuit Protection ≤10A MCB Type C
  • Parasitic Power Consumption 498mW
  • Terminal Capacity 0.5mm² to 1.5mm²
  • Time Out Period 1 second to 240 minutes
  • Working Temperature -10 to +35°C
  • Impact Resistance IK04

Datasheet
