Wylex NMT2SPD3W/1 SPD Surge Protection Device Type 2

Name: Wylex NMT2SPD3W/1 SPD Surge Protection Device Type 2
Brand: Wylex
SKU: NMT2SPD3W/1
Price: 34.04 GBP
Availability: InStock

SKU NMT2SPD3W/1

£34.04 - £34.04

£34.04 inc VAT £28.37 exc VAT

£34.04 - £34.04

£34.04 inc VAT £28.37 exc VAT inc VAT £28.37 exc VAT

Availability:

57 in stock, ready to be shipped

Quantity

Estimated delivery time: Next working day

Description

Type 2 SPD kit. For Wylex consumer units and NH L range Type A SPN Distribution Boards. DIN rail mounting, single module, including all connections. Status indication and volt free contact for remote monitoring

Specification

System configuration TN-C-S Yes
System configuration TN-S Yes
System configuration TT Yes
Nominal discharge surge current (8/20) 20 kA
Short-circuit breaking capacity (Isccr) 25 kA
Max. continuous voltage AC 275 V
Max. discharge surge current (8/20) 40 kA
Mounting method DIN rail (top hat rail) 35 mm
Construction size 1 modular spacing
Voltage protection level 1.3 kV
Max. conductor cross section solid (solid, stranded) 25 mm²
Voltage protection level L-N 1.3 kV
Voltage protection level N-PE 1.3 kV
With remote signalling contact Yes
Integrated backup fuse No
Category type 2 Yes
Degree of protection (IP) IP20
Product Standard/s IEC EN 61643-11
Frequency 50 Hz
CE Conformity Yes
WEEE Symbol Yes
UKCA Conformity Yes

Datasheet

Product Dimensions

Height 85 mm
Width 18 mm
Depth 70 mm
