BG Nexus EMTDSW Euro Module Slave Touch LED Dimmer White

BG Nexus EMTDSW Euro Module Slave Touch LED Dimmer White

SKU EMTDSW
£3.98 - £3.98
£3.98 inc VAT £3.32 exc VAT
£3.98 - £3.98
£3.98 inc VAT £3.32 exc VAT inc VAT £3.32 exc VAT

Standard Shipping

Estimated delivery time: 3-4 days

Description

Main Features:

  • Intelligent trailing edge dimmers have a lower minimum load
    than leading edge dimmers, offering greater compatibility for
    LED, Halogen, CFL and Incandescent lamps
  • Soft start brings the lights to a set level in around 1 second and
    extends the life of lamps
  • Overload protection prevents failure if you mistakenly connect
    your dimmer to too many lights or transformers, and will turn
    the lights down or off until the load is corrected
  • Smooth dimming control
  • Silent operation - no noise when dimming
  • Support for lower wattage lamps eliminates flicker
  • Touch control
  • Secondary switch option for 2-way lights (2nd switch in the
    circuit)
  • Minimum mounting box depth: 25mm
Specification
  • Standard(s) - BS EN 60669-2-1
  • Voltage - 200-250V AC
  • Dimmable LED - 5-100W
  • Tungsten/Incandescent - 5-200W
  • Halogen - 20-200W
  • Dimmable Compact Fluorescent (CFL) - 5-100W
  • Type - Trailing Edge
  • Terminal Capacity - 3 x 1mm² 2 x 1.5mm² 1 x 2.5mm²
  • RoHS Directive - Yes
  • WEEE Directive

Product Dimensions

  • Width (mm) - 25
  • Height (mm) - 50.2
  • Mounting Box Depth (mm) - 25
