BG NBS15 10AX TP Fan Isolator Switched Brushed Steel

SKU NBS15
Original price £8.80 - Original price £8.80
Original price
£8.80 inc VAT £7.33 exc VAT
£8.80 - £8.80
Current price £8.80 inc VAT £7.33 exc VAT inc VAT £7.33 exc VAT
Availability:
12 in stock, ready to be shipped

Standard Shipping

Estimated delivery time: Next working day

Description

 Main Features:

  • Sleek and slim profile with softly rounded edges
  • Fixed integrated plastic gasket to protect metal edges from moisture
  • Colour matched fixing screws
  • Captive, backed out terminal screws for fast installation
  • Easy to install, supplied with fixing screws and installation instructions
  • 10 Amp, 10AX inductive rated
  • The Fan Isolator switch has a triple pole switching design, however can be used for double pole applications if required.
Specification
  • Standard(s) - BS EN 60669-2-4
  • Rating - 10 Amp
  • Voltage - 250V AC
  • Switch Type - Triple Pole
  • Terminal Capacity -4 x 1mm² 4 x 1.5mm² 2 x 2.5mm² 1 x 4.0mm²
  • RoHS Directive - Yes
  • WEEE Directive - Yes
  • Mounting Box Depth (Min) - 16mm

Datasheet

Product Dimensions

  • Width (mm) - 86
  • Height (mm) - 86
